Light Management System: Advanced Optical System
Locking Dial: No
Magnification Type: Variable
Motion Sensor Technology (MST): No
Nightvision Compatible Illumination: No
Reticle Focal Plane: Second Focal Plane
Revolution Indicator: No
Reticle: Duplex
Rezero Type: Set Screw
Reticle Type: Second Focal Plane
Adjustable Objective: No
Side Focus: No
Windage Adjustment Type: Finger Click
Weight (oz): 14.6
Elevation Adjustment Value per Click: 1/4MOA
Elevation Adjustment Range (MOA): 60
Elevation Adjustment Range (MIL): 17
Elevation Adjustment Range (cm @ 100m): 175
Elevation Adjustment Per Revolution: 15 MOA
Elevation Dial Travel Limit: 14MOA
Windage Adjustment Value per Click: 1/4MOA
Windage Adjustment Range (MOA): 60
Windage Adjustment Range (MIL): 17
Windage Adjustment Range (cm @ 100m): 175
Windage Adjustment Per Revolution: 15 MOA
Magnification Max: 9
Magnification Min: 3
Objective Lens Diameter (mm): 50
Linear FOV Low Mag (ft@100yds): 33.1
Linear FOV High Mag (ft@100yds): 13.6
Angular FOV Low Mag (Degrees): 6.3
Angular FOV High Mag (Degrees): 2.6
Eye Relief Low Mag (in): 4.2
Eye Relief High Mag (in): 3.7
Fixed Parallax-Free Distance (yd): 150
